FTTH Plastic Drop Wire Clamp Black Cable Installation kits for 2*3mm 2*5mm cable
Drop wire clamp is commonly used to hold telephone drop wire in place at drive hooks, span clamps, and other drop attachments. A wire clamp is made up of three parts: a shim, a shell, and a wedge with a bail wire. The fiber wire clamps come in two varieties: 1 pair to 2 pair wire clamps and 6 pair wire clamps. The plastic wire clamps have a number of advantages, including durability, cost effectiveness, and corrosion resistance. Because of its strong anti-corrosion performance, this product is highly recommended. In addition, we can make stainless iron drop wire clamps in addition to stainless steel wire clamps.
The plastic wire clamps are available in a range of lengths and materials. All of them can be adjusted to meet your individual needs.
Features
l Good anti-corrosion performance
l High strength
l Abrasion and wear resistant.
l Maintenance-free.
l Easy installation.
l The serrated shim increases the adhesion of stainless steel wire clamp on cables and wires.
l The dimpled shims protect the cable jacket from being damaged.
Real Photos
Specification:
| Model | ODWAC-25 |
| Name | FTTH Accessories Plastic Fiber Optic Cable Drop Wire Tension Clamp with UV Resistance |
| Housing & Wedge | Nylon UV Resistance |
| Color | Black |
| Load retention capability | 100kg |
| Thickness of drop wire | 2x5mm |
| Application | Indoor and Outdoor installation
Effective and time saving for cabling. |
| Usage | FTTH |
How to use?
Application:
Applied outdoor,for installation on the telecommunication supports,between the buildings and industrial constructions to fix and protect optical cables.
